Technical specifications

Number of wheels: 4

Color: Bronze Gold

Material: Aluminium

Front wheel size: 175 x 50 mm (7 x 2″)

Rear wheel size: 200 x 65 mm (8 x 2.5″)

Ground Clearance: (Tiller)60 mm (2.4″)

Length: 990 mm (39″)

Width: 570 mm (22.5″)

Complete weight: 21.1 kgs (46 lbs including battery & seat)

Weight without seat: 14.3 kgs (31 Ibs)

Weight of seat: 5 kgs (11 Ibs included seat frame)

Max Loading:120 kgs (264 Ibs)

Turn Radius: 930 mm (36.6″)

Motor Output: 260W

Transmission: Worm drive differential gearbox

Reverse: Forward/Reverse Switch

Brakes: Dynamic braking & Electromagnetic brake

Battery: 24V11.6ah – 1.8kg (4 Ibs)

Charger Off-board: 24volt 2 amp

Max Speed: 6.5 kph (4 mph)

2nd speed choice: 3.8 kph (2.4 mph)

Slope grade ability: Max recommended-8 degrees

Travel Distance: Up to 10-13 km (6.2-8 miles)

Speed Reduction System: Reduces operating speed to a safe level when turning
